Installing a VPN-Server on Windows Server 2019 (2024)

A Virtual Private Network (VPN) connection is a private network that connects multiple devices remotely through the Internet. Traffic over the VPN network is sent encrypted. With a VPN connection, you add an extra layer of security to your (company) network. For a more detailed explanation of VPN networks, see our in-depth blog post "What is a VPN connection?".

In this tutorial, we show you how to install a VPN server in Windows Server 2019 and make a VPN connection from another computer, for example, your computer at home.

The steps in this tutorial require an SSL certificate via IIS on your VPN server.

Installing a VPN server

Step 1

Connect to your Windows Server via Remote Desktop or the VPS console.

Step 2

Open the 'Server Manager' via the Windows Start button > Server Manager.

Step 3

Click on 'Add roles and features' in the dashboard of the Server Manager.

Step 4

You will now see the 'Before You Begin' page. You can select not to see this page again when you add roles & features in the future. Click on 'Next' after you have read the points under 'before you continue'.

Step 5

Under 'Installation Type' you can choose between 'Role-based or feature-based' and 'Remote Desktop Services installation'. Choose 'Role-based or feature-based' and continue to the next step.

Step 6

Select the desired VPS on which you want to perform the installation. If you use an Active Directory and it contains several VPSs, these are listed in this overview. If you do not use Active Directory, you will see the VPS on which you go through this tutorial.

Step 7

On the next page, you can select a 'Server Role'. Select 'Remote Access' (including responsible for VPN) and click on 'Next'. You do not have to adjust any other options already checked.

Step 8

You do not have to select or adjust features. Click immediately on 'Next' to continue.

Step 9

You will see a description of the Remote Access role. Click on 'Next' to continue.

Step 10

Then select the 'role services' of the Remote Access role you want to use. Click here on 'DirectAccess and VPN (RAS)'.

You should probably see a pop-up with an overview of role services and features that need to be added to use the DirectAccess and VPN (RAS). Click on 'Add Features' to have it added automatically.

After this, you return to the 'Role Services' screen and the option 'DirectAccess and VPN (RAS)' is checked. Also, check the 'Routing' option and click 'Next' to proceed to the next step.

Step 11

Before the installation starts, you will see a confirmation of the options you selected in the previous steps.

Check 'Restart the destination server automatically if required': it is always important (if an installation requires it) to restart your server to ensure the proper functioning of the role/feature.

Finally, click on 'Install'. The installation itself takes a few minutes, so feel free to grab a cup of coffee before proceeding to the next step.

Authorize users to connect to your VPN server

Step 1

Before a user can connect to your VPN server, that user must be authorized for Remote Access.

Not using Active Directory? Then click on the Windows start button, search for 'computer' and click on 'Computer Management' in the results.

Do you use an Active Directory? Then click on the Windows start button, search for 'group' and click on 'Group Policy Management' in the results.

Step 2

You are free to create a new user for your VPN connection or use an existing one. Click on 'Local Users and Groups' > 'Users'.

Existing user: Click on the name of the user
New user: Right-click on an empty piece and then 'New User'. Enter the name of the new user, optionally disable 'User must change password at next logon', and enter a password.

After creating the new user, close the 'New User' screen and double click on the name of the account.

Step 3

Click on the 'Dial-in' tab, under 'Network Access Permission' check the option 'Allow access' and finally click 'Apply' and 'OK' to confirm your changes.

That's it! You can now connect to your VPN server. We explain how this works in the next section.

Connect to your VPN network

This tutorial assumes a Windows computer/laptop. For MacOS, you can use this guide from Apple. To connect to your VPN server, enter the IP address of your VPS and as VPN type 'SSTP'.
You go through the steps once per computer. You only need the last step to connect to your VPN server from now on.

Step 1

Now that your VPN server is ready and your user is authorized, it's time to connect to your VPN server. First, you need to add the VPN connection to your (client) computer/laptop once.

Click the Windows Start button and the Settings icon.

Step 2

Then click on 'Network & Internet'.

Step 3

Click on 'VPN' on the left and then on 'Add a VPN connection'.

Step 4

Enter the details on the 'Add a VPN connection' screen that appears. Mind the following:

Select 'Windows (built-in)' as the VPN provider
As 'Server name or address', use the IPv4 address of your server, or a domain name that refers to your VPS.
Choose as VPN type: 'Secure Socket Tunneling Protocol (SSTP)'.

Step 5

All your internet traffic is standard over the VPN and uses the default gateway of the VPN server. This means that if you navigate on a client computer in a browser, you are using the connection of your VPS.

We assume in this tutorial that for your regular internet traffic you would like to use your own connection (for example in connection with speed and the data traffic limit of your VPS). You can achieve this by setting your own connection as the default gateway for your VPN as follows:

Click on the Windows Start button, type 'Internet Options' and click on the top result.

Step 6

Go to the 'Connections' tab, select your VPN connection and click 'Settings'.

Step 7

In the window that appears, click on 'Properties'.

Step 8

Go to the 'Networking' tab and select 'Internet Protocol Version 4 (TCP / IPv4)' followed by 'Properties'.

Step 9

Click on 'Advanced'.

Step 10

Uncheck 'Use default gateway on remote network' and click 'OK'.

You will now return to the window from step 9. Click on 'OK' there as well and repeat steps 8 to 10, but then for 'Internet Protocol Version 6 (TCP / IPv6)'.

Then click 'OK' at each screen where you return until you return to the 'Internet Properties' screen from step 6 and click 'Apply' and 'OK' there.

Step 11

Finally, click on the network icon at the bottom right of your screen and click on the name of your VPN connection, followed by 'Connect'. From now on, this is the only step you need to go through to reconnect to your VPN server.

Use Cases

Now that your VPN connection is working, you may be wondering what you can do with it. A VPN connection is powerful in combination with a firewall. You can set a scope for a rule in most firewall software, for example in Windows Defender Firewall with Advanced Security, see for example our tutorial on changing the Remote Desktop port.

By only allowing the range or specific addresses of your VPN connection as Remote IP address in the scope of your firewall rule, you limit access to the associated service to those IP addresses. Some examples of applications are:

Restrict access to the Remote Desktop port to the IP range of your VPN network (10.10.0.0/24 for example).
Restrict access to a website that you host on a server in your VPN network. This is useful, for example, for an internal administration system that can be reached via a web interface/website. You achieve this by limiting access to ports 80 and 443 on the server hosting your website to the IP range of your VPN network.
Restrict access to an SMB server by restricting access to port 445 on the SMB server to the IP range of your VPN network.

That brings us to the end of this tutorial for setting up a VPN server in Windows Server 2019.
